The Story
Heatsink Specifications:
Dimension：L125 mm x W110 mm x H135 mm
Weight：700g
Heat pipes：6mm heatpipe x 6 units
Copper Base：C1100 Pure copper nickel plated
TL-D12B FAN Spec：
Dimension：L120 mm x W120 mm x H25 mm
Weight：120g
Rated Speed：1500 RPM±10% (MAX)
Noise Level：25.6 dBA
Air Flow：66.87 CFM (MAX)
Air Pressure：1.53 mm H2O (MAX)
Ampere：0.20 A
Connector：4 Pin (PWM Fan connector)
Bearing Type : S-FDB Bearing
Compatibility:
Intel：LGA115X/1200/1700/2011/2066
AMD：AM4/AM5
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Heatsink Specifications:
Dimension：L125 mm x W110 mm x H135 mm
Weight：700g
Heat pipes：6mm heatpipe x 6 units
Copper Base：C1100 Pure copper nickel plated
TL-D12B FAN Spec：
Dimension：L120 mm x W120 mm x H25 mm
Weight：120g
Rated Speed：1500 RPM±10% (MAX)
Noise Level：25.6 dBA
Air Flow：66.87 CFM (MAX)
Air Pressure：1.53 mm H2O (MAX)
Ampere：0.20 A
Connector：4 Pin (PWM Fan connector)
Bearing Type : S-FDB Bearing
Compatibility:
Intel：LGA115X/1200/1700/2011/2066
AMD：AM4/AM5
