The Story
Compatibility:
Intel：LGA115X/1200/1700/1851
AMD：AM4/AM5
Technical Spec :
Heatsink Specifications:
Dimension: L120 mm x W46 mm x H154 mm
Weight: 545g
Heat pipes: 6mm heatpipe x 4 units
TL-C12B V2 FAN Spec：
Dimension: L120 mm x W120 mm x H25 mm
Rated Speed: 1500 RPM±10% (MAX)
Noise Level: 25.6 dBA
Air Flow: 66.17 CFM (MAX)
Air Pressure: 1.53mm H2O (MAX)
Ampere: 0.20 A
Connector: 4 Pin (PWM Fan connector)
Bearing Type : S-FDB Bearing
TL-C12RB V2 FAN Spec：
Dimension: L120 mm x W120 mm x H25 mm
Rated Speed: 1500 RPM±10% (MAX)
Noise Level: 25.6 dBA
Air Flow: 58 CFM (MAX)
Air Pressure: 1.53mm H2O (MAX)
Ampere: 0.20 A
Connector: 4 Pin (PWM Fan connector)
Bearing Type : S-FDB Bearing
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Compatibility:
Intel：LGA115X/1200/1700/1851
AMD：AM4/AM5
Technical Spec :
Heatsink Specifications:
Dimension: L120 mm x W46 mm x H154 mm
Weight: 545g
Heat pipes: 6mm heatpipe x 4 units
TL-C12B V2 FAN Spec：
Dimension: L120 mm x W120 mm x H25 mm
Rated Speed: 1500 RPM±10% (MAX)
Noise Level: 25.6 dBA
Air Flow: 66.17 CFM (MAX)
Air Pressure: 1.53mm H2O (MAX)
Ampere: 0.20 A
Connector: 4 Pin (PWM Fan connector)
Bearing Type : S-FDB Bearing
TL-C12RB V2 FAN Spec：
Dimension: L120 mm x W120 mm x H25 mm
Rated Speed: 1500 RPM±10% (MAX)
Noise Level: 25.6 dBA
Air Flow: 58 CFM (MAX)
Air Pressure: 1.53mm H2O (MAX)
Ampere: 0.20 A
Connector: 4 Pin (PWM Fan connector)
Bearing Type : S-FDB Bearing
